A 2-in-1 folding picnic table and bench combo is a versatile piece of outdoor furniture that can save space and provide both seating and dining functionality. In this guide, you'll learn how to build your own combo unit from scratch. This project is perfect for woodworking enthusiasts and requires some basic carpentry tools. Let’s get started!

Materials Needed:

• 8 pieces of 2x4 lumber (8 feet long)

• 4 pieces of 1x6 lumber (6 feet long)

• 3 pieces of 2x6 lumber (8 feet long)

• 2 sets of 4-inch heavy-duty hinges (6 hinges total)

• 3-inch wood screws

• 1 1/2-inch wood screws

• Wood glue

• Measuring tape

• Circular saw or table saw

• Power drill

• Sandpaper or sander

• Wood finish or paint (optional)

Tools Needed:

• Tape measure

• Power drill

• Saw (circular or table saw)

• Screwdriver

• Clamps

• Sander

Step-by-Step Instructions:

1. Cut the Wood Pieces

First, measure and cut your lumber based on the following dimensions:

• Seat slats: Cut 6 pieces of 2x4 lumber, each 42 inches long.

• Tabletop slats: Cut 4 pieces of 2x6 lumber, each 60 inches long.

• Leg supports: Cut 4 pieces of 2x4 lumber, each 30 inches long.

• Bench legs: Cut 4 pieces of 2x4 lumber, each 18 inches long.

• Table legs: Cut 4 pieces of 2x6 lumber, each 28 inches long.

• Cross braces: Cut 4 pieces of 1x6 lumber, each 36 inches long.

Make sure all your pieces are cut square and are free of any rough edges. Sand each piece for a smooth finish.

2. Build the Bench Frame

Using the seat slats (2x4s), attach the two 42-inch long pieces to two 18-inch bench legs. Screw the legs into the seat slats using 3-inch screws and wood glue. Repeat this step to make two identical bench frames.

Next, attach a cross brace (36-inch 1x6) to the underside of each bench, about 10 inches down from the top, for added support. Ensure the frame is stable.

3. Construct the Tabletop Frame

Now, build the tabletop frame using the 60-inch long 2x6 lumber pieces. Position the four tabletop slats evenly and screw them together by attaching the 30-inch leg supports at each end. These leg supports will be connected later to the legs.

Add the cross braces between the legs for extra stability. Use clamps to hold the pieces in place while you drill and screw them together.

4. Attach the Hinges

Here’s where the magic happens! Use heavy-duty 4-inch hinges to attach the bench seat frames to the tabletop frame. The hinges will allow the table to fold into a bench or extend out into a picnic table.

• Attach the hinges at the back of each bench seat frame and to the underside of the tabletop’s sides.

• Ensure the hinges are aligned properly so that the table can fold smoothly without any resistance.

5. Install the Legs

Now it’s time to install the legs of the table. Attach the four 28-inch table legs to the underside of the tabletop using screws and wood glue. Ensure that the legs are positioned evenly and are straight.

Attach a 1x6 cross brace diagonally between the legs for added strength. Repeat this for all legs.

6. Test the Folding Mechanism

Once the legs and hinges are securely in place, test the folding mechanism. Fold the bench seat frames up toward the tabletop to form the bench. The seat frames should lock into place when folded and lay flat when extended out as a picnic table.

7. Finish the Table and Bench Combo

After assembling the combo unit, sand the entire structure to smooth out any rough spots. Apply a wood finish, sealant, or paint to protect the wood from outdoor elements. This step will ensure that your picnic table and bench combo lasts longer and can withstand weathering.

Measurements Recap:

• Seat Slats: 42 inches (6 pieces of 2x4)

• Tabletop Slats: 60 inches (4 pieces of 2x6)

• Bench Legs: 18 inches (4 pieces of 2x4)

• Table Legs: 28 inches (4 pieces of 2x6)

• Leg Supports: 30 inches (4 pieces of 2x4)

• Cross Braces: 36 inches (4 pieces of 1x6)

Conclusion:

Congratulations! You've successfully built a 2-in-1 folding picnic table and bench combo. This space-saving furniture can be used in your backyard, at campsites, or even on patios. The folding feature adds versatility, making it a functional addition to any outdoor setting.

Now, grab your favorite outdoor snacks and enjoy your new creation!
